GATE ME Geometric Optics practice

Topic-wise practice1 questions 5 min

1Preview question 1 of 1 · instant answer reveal

A taper hole is inspected using a CMM, with a probe of 2 mm diameter. At a height,

Z = 10

mm from the bottom, 5 points are touched and a diameter of circle (not compensated for probe size) is obtained as 20 mm. similarly, a 40 mm diameter is obtained at a height

Z = 40

mm. The smaller diameter (in mm) of the hole at

Z = 0

Choose one answer to reveal the solution.

This is a 1-question preview. The full 1-question timed test opens after free signup.
